From hors categorie climbs to rollers and flats, this WorldTour level race bike is the pro’s choice for all-rounder performance. The all-new flagship TCR uses system integration and innovative construction methods to deliver a clear advantage on the road.
Key Performance Factors
SYSTEM OPTIMIZATION
The frameset, wheels, cockpit and other parts are engineered, developed and tested together to perform best as a system. The all-new OverDrive Aero steerer tube technology is combined with a Contact SLR AeroLight stem and Contact SLR handlebar to incorporate internal cable routing that also integrates the top cap, cables and spacers in a more aerodynamic, user-friendly setup
WINNING EFFICIENCY
Featuring a greater stiffness-to-weight ratio than the previous generation, along with new aero tube shaping and a lighter overall weight, this uncompromising race bike delivers explosive acceleration and unyielding pedaling stiffness. The result is race-winning performance in the moments that count.
INTEGRATED AERODYNAMICS
From the truncated ellipse shape of frameset tubing to a new cockpit design and component integration, it all adds up to a more streamlined profile that helps give the flagship TCR Advanced SL 0 model a 4.19-watt advantage over the previous generation.
| Sizes | XS, S, M, M/L, L, XL |
| Colors | Black Lava |
| Frame | Advanced SL-Grade Composite, 12x142mm thru-axle, integrated seatpost, disc |
| Fork | Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR XS:37/40cm, S:37/40cm, M:39/42cm, M/L:39/42cm, L:41/44cm, XL:41/44cm |
| Stem | Giant Contact SLR AeroLight XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm |
| Seatpost | Advanced SL-Grade composite, integrated design, -5/ 15mm offset |
| Saddle | CADEX AMP |
| Pedals | N/A |
| Shifters | SRAM RED AXS HRD, ED-RED-E1 |
| Front Derailleur | SRAM RED AXS, FD-RED-E-E1 |
| Rear Derailleur | SRAM RED AXS, FD-RED-E-E1 |
| Brakes | SRAM RED AXS HRD, ED-RED-E1, SRAM PaceLine X rotors [F]160mm, [R]140mm |
| Brake Levers | SRAM RED AXS HRD, ED-RED-E1 |
| Cassette | SRAM RED XG-1290, 12-speed, 10-33 |
| Chain | SRAM RED-E1, 12-speed |
| Crankset | SRAM RED E1, DUB , 35/48 with power meter XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | SRAM DUB, Press Fit |
| Rims | CADEX Max 40 WheelSystem, [F]40mm, [R]40mm |
| Hubs | [F] CADEX R3 Hub, CenterLock, 12mm thru-axle [R] CADEX R3-C48 Aero Hub, 48t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | CADEX Aero Carbon Spoke |
| Tires | CADEX Race GC, tubeless, 700x28c (28mm), folding |
| Extras | Computer mount, tubeless prepared, 33mm max tyre size |
